Nitriding Steel

EN41B is a chromium aluminum molybdenum steel particular as a rule supplied in the solidified and tempered "R" or "S" condition. EN41B "R" condition has a tractable of 700-850 N/mm². EN41B'S' condition has an elastic of 775-925 N/mm².

It offers high wear safe properties together with strength and ductility. It is characterized by its reasonableness for nitriding from which EN41B can give a hard wear resistant case up to 68HRc, superior to anything achievable with the comparative nitriding grade EN40B.

Chemical Composition

Element	Min	Max
Carbon, C	0.35	0.45%
Manganese, Mn	-.--	0.65%
Silicon, Si	0.10	0.45%
Nickel, Ni	-.--	0.40%
Molybdenum, Mo	0.10	1.25%
Chromium,Cr	1.04	1.08%
Sulfur, S	-.--	0.05%
Phosphorous, P	-.--	0.05%
Aluminium	0.90	1.03

Mechanical Properties

Condition	Tensile N/mm²	Yield N/mm²	Elongation %	Izod KCV J	Hardness Brinell
R	700-850	480	16	28	201-255
S	775-925	525	14	16	223-27

Features

Heat Treatment

Tempering

Annealing

Hardening
